Table 1 shows the quick spec.
|
SKU |
NIM-4FXSP |
|
Number of Ports |
4 |
|
ISR G2 comparison |
VIC3-4FXS/DID |
|
Cisco IOS Release |
XE16.5 and above |
Note: “P” version is created due to introduction of new hardware component into the manufacturing process. There is no change in functionality from non-P version.
Table 2 shows the supported routers.
|
SKU |
Description |
|
ISR4451-X/K9 |
1-2G system throughtput, 4 WAN/LAN ports, 4 SFP ports, 10 Core CPU, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC, separate control data and services CPUs |
|
ISR4451-X-AX/K9 |
1Gbps-2Gbps system throughtput, 4 WAN/LAN ports, 4 SFP ports, multi-Core CPU, Dual-power, Security, Voice, WAAS, Intelligrnt WAN, OnePK, AVC, separate control data and services CPUs |
|
ISR4451-X-SEC/K9 |
Cisco ISR 4451 Sec bundle w/SEC license |
|
ISR4451-X-VSEC/K9 |
Cisco ISR 4451 VSEC Bundle, PVDM4-64 w/ UC,SEC Lic,CUBE- 25 |
|
ISR4451-X-V/K9 |
Cisco ISR 4451 UC Bundle. PVDM4-64. UC Lic.CUBE25 |
|
ISR4451-X-AXV/K9 |
Cisco ISR 4451 AXV Bundle.PVDM4-64 w/APP.SEC.UC lic.CUBE-25 |
Table 3 shows the comparison.
|
Part Number |
Number of Ports |
ISR G2 comparison |
Cisco IOS Release |
|
NIM-2FXO |
2 |
VIC2-2FXO |
XE3.13.4, XE3.14.3, XE3.15.1, XE3.16 and above |
|
NIM-4FXO |
4 |
VIC2-4FXO |
XE3.13.4, XE3.14.3, XE3.15.1, XE3.16 and above |
|
NIM-2FXS |
2 |
VIC3-2FXS/DID |
XE3.13.4, XE3.14.3, XE3.15.1, XE3.16 and above |
|
NIM-4FXS |
4 |
VIC3-4FXS/DID |
XE3.13.4, XE3.14.3, XE3.15.1, XE3.16 and above |
|
NIM-2FXS/4FXO |
6 |
VIC2-4FXO and VIC3-2FXS/DID |
XE3.14.3, XE3.15.1, XE3.16 and above |
|
NIM-2FXSP |
2 |
VIC3-2FXS/DID |
XE16.5 and above |
|
NIM-4FXSP |
4 |
VIC3-4FXS/DID |
XE16.5 and above |
|
NIM-2FXS/4FXOP |
6 |
VIC2-4FXO and VIC3-2FXS/DID |
XE16.5 and above |
|
NIM-4E/M |
4 |
VIC3-2E/M |
XE3.14.3, XE3.15.1, XE3.16 and above |
|
NIM-2BRI-NT/TE |
2 |
VIC2-2BRI-NT/TE |
XE3.14.3, XE3.15.1, XE3.16 and above |
|
NIM-4BRI-NT/TE |
4 |
VIC2-2BRI-NT/TE |
XE3.14.3, XE3.15.1, XE3.16 and above |
NIM-4FXSP Specification |
|
|
Number of Ports |
4 |
|
ISR G2 comparison |
VIC3-4FXS/DID |
|
Cisco IOS Release |
XE16.5 and above |
|
Telnet or console |
Remote and local configuration, monitoring, and troubleshooting from Cisco IOS XE Software command-line interface. |
|
Simple Network Management Protocol (SNMP) |
● Router and data service unit (DSU)/channel service unit (CSU) managed by single SNMP agent; router, DSU, and CSU appear as a single network entity to user ● Standard MIB (MIB II) ● Cisco Integrated DSU/CSU MIB ● RFC 1406 T1 MIB, including Alarm Detection and Reporting |
|
SNMP traps |
Generated in response to alarms |
|
Standard |
TIA-968-B (USA) CS-03 (Canada) AS/CA S003 (Australia) PTC220 (New Zealand) |
|
Emission |
47 CFR Part 15 CISPR22: Edition 6.0: 2008 CNS13438: 2006 EN 300 386 V1.6.1 EN 55022:2010 EN61000-3-2: 2006 [Inc amd 1 '&' 2] EN61000-3-3: 2008 ICES-003 Issue 5: 2012 KN 22: 2009 TCVN 7189: 2009 VCCI: V-3/2013.04 |
|
Immunity |
CISPR24: 2010 EN 300 386 V1.6.1 EN55024: 2010 KN24: 2011 TCVN 7317: 2003 |
