SKU |
AIR-AP1562E-B-K9 |
|
Type |
Wireless access point |
|
Form Factor |
External |
|
Data Transfer Rate |
1.3 Gbps |
|
Compliant Standards |
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at |
|
Wireless Protocol |
802.11a/b/g/n/ac Wave 2 |
|
Power Over Ethernet (PoE) |
PoE+ |
|
Wi-Fi Bands |
2.4 GHz, 5 GHz |
Cisco AIR-AP1562D-A-K9 has these benefits:
①802.11ac Wave 2 radio
Provides up to 1.3-Gbps data rates with 3 x 3 Multiple Input, Multiple Output (MIMO) and up to three spatial streams.
②Multiuser MIMO (MU-MIMO)
Allows transmission of data to multiple 802.11ac Wave 2-capable clients simultaneously to improve client experience; prior to 802.11ac Wave 2, access points could transmit data to only one client at a time, typically referred to as single-user MIMO.
③Flexible deployment modes
Allows for deployment of the 1560 in a variety of ways including point -to-point and mesh networks; it can also be deployed with the Cisco Mobility Express Solution, which is ideal f or small to medium -sized deployments that supports multiple access points without a physical controller; all deployment modes are easy to set up and configure.
④Small Form-Factor Pluggable (SFP) port
Supports optical fiber-based network connectivity for remote locations.
Table 2 shows the comparison.
|
Product Name |
AIR-AP1562E-B-K9 |
|
|
Antenna |
External |
Internal |
|
Data Transfer Rate |
1.3 Gbps |
1.3 Gbps |
|
Wireless Protocol |
802.11a/b/g/n/ac Wave 2 |
802.11a/b/g/n/ac Wave 2 |
|
Wi-Fi Bands |
2.4 GHz, 5 GHz |
2.4 GHz, 5 GHz |
|
Power Over Ethernet (PoE) |
PoE+ |
PoE+ |
AIR-AP1562E-B-K9 Specification |
|
|
Networking |
|
|
Type |
Wireless access point |
|
Form Factor |
External |
|
Connectivity Technology |
Wireless |
|
Data Transfer Rate |
1.3 Gbps |
|
Data Link Protocol |
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
|
Compliant Standards |
IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at |
|
Features |
2T2R MIMO technology, Auto-sensing per device, Beamforming technology, CleanAir technology, ClientLink technology, Cyclic shift diversity (CSD), DFS support, Dynamic path selection (DPS), MAC address authentication, MAC address filtering, Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Radio resource management (RRM), Reset button, VPN passthrough |
|
Network Transport Protocol |
IPSec, L2TP |
|
Wireless Protocol |
802.11a/b/g/n/ac Wave 2 |
|
Power Over Ethernet (PoE) |
UPOE |
|
Wi-Fi Bands |
2.4 GHz, 5 GHz |
|
Interface Provided |
|
|
WAN DMZ |
WAN |
|
Type |
Management |
|
Connector Type |
SFP (mini-GBIC) |
|
Miscellaneous |
|
|
Compliant Standards |
ANSI / IEEE 587 C62.41, ARIB STD-T66, ARIB STD-T71, AS/NZS 4268.2003, EN 300 328, EN 301 489-1, EN 301 893, EN 60068-2-5, EN 60950, EN 60950 Second Edition, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, FCC OET Bulletin 65c, FCC Part 15.107, FCC Part 15.109, FCC Part 15.247, FCC Part 15.407, IEC 60529 IP67, IEC 60950 Second Edition, MIL-STD-810, NEMA 250-2008, NEMA Type 4X, RSS-102, RSS-210, UL 60950 Second Edition |
|
Authentication Method |
Extensible Authentication Protocol (EAP), X.509 certificates |
|
Encryption Algorithm |
AES, LEAP, PEAP, TLS, TTLS, WPA, WPA2 |
|
Antenna |
|
|
Antenna Form Factor |
External detachable |
|
Environmental Parameters |
|
|
Min Operating Temperature |
-40 °F |
|
Max Operating Temperature |
131 °F |
|
Header |
|
|
Compatibility |
PC |
|
Country Kits |
United States |
|
Manufacturer |
Cisco Systems |
|
Product Line |
Cisco Aironet |
|
Model |
1562E |
|
Brand |
Cisco |
|
Capacity |
|
|
Type |
Spatial streams |
|
Value |
2 |
|
Dimensions |
|
|
Width |
6.7 in |
|
Depth |
3.9 in |
|
Height |
9 in |
|
Chassis |
|
|
Ruggedized Design |
Outdoor |
