Product Code |
AIR-AP2802E-H-K9 |
|
Frequency band and 20-MHz operating channels |
H (H regulatory domain): - 2.412 to 2.472 GHz; 13 channels - 5.150 to 5.350 GHz; 8 channels - 5.745 to 5.825 GHz; 5 channels |
|
Antenna |
External Antenna |
|
Features |
- 4x4 MU-MIMO with three spatial streams - MRC - 802.11ac Beamforming - 20-, 40-, 80, 160-MHz channels - PHY data rates up to 5.2 Gbps - Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx) - 802.11 DFS - CSD support |
|
Interfaces |
- 2 x 100/1000BASE-T autosensing (RJ-45) - Management console port (RJ-45) - USB 2.0 (enabled via future software) |
|
System memory |
- 1024 MB DRAM - 256 MB flash |
|
Dimensions (W x L x H) |
8.66 x 8.77 x 2.50 in. |
|
Net Weight |
4.6 lb (2.09 kg) |
AIR-AP2802E-H-K9 Specification |
|
| Networking | |
| Type | Wireless access point |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 5.2 Gbps |
| Data Link Protocol | IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Compliant Standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ad (LACP) |
| Status Indicators | Boot state, Error, Status |
| Features | 4T4R MIMO technology, Auto-sensing per device, Beamforming technology, CleanAir technology, ClientLink 4.0 technology, Cross AP Noise Reduction, Cyclic shift diversity (CSD), DFS support, High Density Experience (HDX), Link Aggregation Control Protocol (LACP), Maximum Ratio Combining (MRC), MIMO equalization, Optimized AP Roaming, Packet aggregation A-MPDU, Packet aggregation A-MSDU |
| Wireless Protocol | 802.11a/b/g/n/ac Wave 2 |
| Wi-Fi Bands | 2.4 GHz, 5 GHz |
| Interface Provided | |
| Qty | 1 |
| Type | Console |
| Connector Type | RJ-45 |
| Miscellaneous | |
| Included Accessories | Ceiling grid clip, Low profile bracket |
| Service | |
| Support Details Type | Limited warranty |
| Support Details Service Included | Advance hardware replacement |
| Support Details Full Contract Period | Lifetime |
| Header | |
| Compatibility | PC |
| Country Kits | China |
| Manufacturer | Cisco Systems |
| Packaged Quantity | 1 |
| Product Line | Cisco Aironet |
| Model | 2802E |
| Brand | Cisco |
| Service & Support Details | |
| Response Time | 10 days |
| Software | |
| Type | CAPWAP Software Image |
| Capacity | |
| Type | Spatial streams |
| Value | 3 |
| Dimensions & Weight | |
| Width | 8.7 in |
| Depth | 8.8 in |
| Height | 2.5 in |
| Service & Support | |
| Type | Limited lifetime warranty |
| Chassis | |
| Ruggedized Design | Indoor |
