Product

Huawei FusionServer RH5885 V3 Rack Server

Form factor

4U rack server

Number of processors

2 or 4

Processor model

Intel® Xeon® E7-4800 v3/v4 or E7-8800 v3/v4 processors, with an L3 cache capacity of 60 MB maximum

Number of DIMM slots

48 DIMMs, up to 3 TB (64 GB DIMMs)

Memory

48 DIMMs

Internal Storage

8 or 23 x 2.5-inch SAS/SATA HDDs or SSDs, or 8 x 2.5-inch SAS/SATA HDDs + 4 x 2.5-inch NVMes

RAID

RAID 0, 1, 10, 5, 50, 6, or 60

(Optional) Configured with a supercapacitor or Battery Backup Unit (BBU) for power-off protection

LOM Network Ports

2 GE or 4 GE ports, or 2 x 10 GE ports

PCIe Expansion

Up to 8 PCIe slots (including one for RAID)

Fan Modules

5 hot-swappable fan modules in N+1 redundancy mode

Power Supply Units

2 hot-swappable PSUs in 1+1 redundancy mode

4 hot-swappable PSUs in 2+2 redundancy mode

Management

Provides independent ports; supports standard management interfaces, such as SNMP and IPMI; provides GUI, remote KVM, virtual media, SOL, Predictive Failure Analysis (PFA), intelligent power supply, remote control, and hardware monitoring

Supports Huawei eSight management software and integration with third-party management systems, such as VMware vCenter, Microsoft System Center, and Nagios

Operating Temperature

5ºC to 40ºC (41ºF to 104ºF), ASHRAE Class A3 compliant

Dimensions (H x W x D)

447 mm x 790 mm x 175 mm (17.60 in. x 31.10 in. x 6.89 in.)

Product

Huawei FusionServer RH5885 V3 Rack Server

Huawei FusionServer 5288 V3 rack server

Huawei FusionServer RH5885H V3 Rack Server

Form factor

4U rack server

4 U rack server

4U rack server

Number of processors

2 or 4

One or two

2 or 4

Processor model

Intel® Xeon® E7-4800 v3/v4 or E7-8800 v3/v4 processors, with an L3 cache capacity of 60 MB maximum

Intel® Xeon® E5-2600 v3/v4 series processors

Intel® Xeon® E7-4800 v3/v4 or E7-8800 v3/v4 processors, with an L3 cache capacity of 60 MB maximum

Number of DIMM slots

48 DIMMs, up to 3 TB (64 GB DIMMs)

8 or 16 slots for DDR4 RDIMMs or LRDIMMs

96 DIMMs, up to 6 TB (using 64 GB DIMMs)

Memory

48 DIMMs

16 DDR4 RDIMMs/LRDIMMs

96 DIMMs

Internal Storage

8 or 23 x 2.5-inch SAS/SATA HDDs or SSDs, or 8 x 2.5-inch SAS/SATA HDDs + 4 x 2.5-inch NVMes

5288 V3 with 40 hard disks
Front:

Rear:

5288 V3 with 28 hard disks
Front:

Rear:

8 or 23 x 2.5-inch SAS/SATA HDDs or SSDs, or 8 x 2.5-inch SAS/SATA HDDs +
