Product Code |
AR2201-48FE |
|
Services Interfaces |
WAN interfaces: 1 GE electrical interface and 1 GE combo interface LAN interfaces: 48 × 10/100M auto-sensing Ethernet electrical interfaces |
|
Expansion Card Slots |
1 |
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Power module type |
Built-in AC power module |
|
Fan type |
Built-in fans |
|
Dimensions (W x D x H) |
44.2 cm x 31.49 cm x 4.36 cm |
|
Pack Weight |
5.8 Kg |
|
Software Version |
V200R003C00 and later |
Table 2 shows the recommended optical transceivers of the Services Interfaces.
|
Model |
Description |
|
FE-SFP Optical Transceiver |
|
|
SFP-FE-SX-MM1310 |
Optical Transceiver,SFP,100M/155M,Multi-mode Module(1310nm,2km,LC) |
|
eSFP-FE-LX-SM1310 |
Optical Transceiver,eSFP,100M/155M,Single-mode Module(1310nm,15km,LC) |
|
S-SFP-FE-LH40-SM1310 |
Optical Transceiver, eSFP, FE, Single-mode Module(1310nm,40km,LC) |
|
GE-SFP Optical Transceiver |
|
|
eSFP-GE-SX-MM850 |
Optical Transceiver, eSFP, GE, Multi-mode Module(850nm,0.55km,LC) |
|
SFP-GE-LX-SM1310 |
Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC) |
|
S-SFP-GE-LH40-SM1310 |
Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,40km,LC) |
|
S-SFP-GE-LH40-SM1550 |
Optical Transceiver, eSFP, GE, Single-mode Module(1550nm,40km,LC) |
Table 3 shows the comparison between AR2201-48FE and AR2202-48FE.
|
Model |
AR2201-48FE |
AR2202-48FE |
|
Services Interfaces |
WAN interfaces: 1 GE electrical interface, 1 GE combo interface
LAN interfaces: 48 × 10/100M auto-sensing Ethernet electrical interfaces |
WAN interfaces: 1 GE electrical interface, 1 GE combo interface, 1 SA interface, 1 E1 interface
LAN interfaces: 48 10/100M auto-sensing Ethernet electrical interfaces |
|
Expansion Card Slots |
1 |
1 |
|
Memory |
512 MB |
512 MB |
|
Flash |
512 MB |
512 MB |
AR2201-48FE Specifications |
|
|
Type |
AR2201-48FE,2GE WAN(1GE Combo),1 USB,48FE LAN,60W AC Power |
|
Software Version |
V200R003C00 and later |
|
Dimensions (W x D x H) |
442.0 mm x 314.9 mm x 43.6 mm |
|
Memory |
512 MB |
|
Flash |
512 MB |
|
Hard disk |
None |
|
Service and Router Unit (SRU) |
Not supported |
|
Network data encryption (SM1/2/3/4) card |
Not supported |
|
Management interface |
Supported |
|
Console interface (RJ45) |
Supported |
|
Console interface (Mini USB) |
Supported |
|
USB 2.0 interface (host) |
Supported |
|
USB 2.0 interface (OTG) |
None |
|
Micro SD card (default) |
Not supported |
|
Antenna interfaces |
None |
|
Service interfaces (standard configuration) |
WAN interfaces: 1 GE electrical interface and 1 GE combo interface LAN interfaces: 48 10/100M auto-sensing Ethernet electrical interfaces |
|
Interface number |
LAN interfaces: FE0-FE47 |
|
Extended slots |
1 |
|
Power module type |
Built-in AC power module |
|
Rated voltage range |
100 V AC/240 V AC, 50 Hz/60 Hz |
|
Maximum voltage range |
90 V AC to 264 V AC, 47 Hz to 63 Hz |
|
RPS150 |
Supported |
|
PoE |
Not supported |
|
Maximum PoE power for PDs |
None |
|
PoE+ interfaces |
None |
|
Weight |
4.5 kg (9.92 lb) |
|
Mounting brackets |
Standard configuration |
|
Operating temperature |
0°C to 45°C (32°F to 113°F) |
|
Operating altitude |
0-4000 m (0-13123 ft.) |
|
Fan type |
Built-in fans |
|
Heat dissipation mode |
Forcible air cooling |
|
Installation mode |
Rack mounting |
