Table 1 shows the Quick Specs.
|
Product Code |
Huawei Router - AR2240C |
|
Memory |
Configured with SRU40/SRU60/SRU80/SRU100: 2 GB Configured with SRU200: 4 GB |
|
Flash |
16 MB |
|
Service interfaces (standard configuration) |
WAN interfaces: Configured with SRU40/SRU60/SRU80/SRU100: 1 GE electrical interface and 2 GE combo interfaces Configured with SRU200: 2 10 GE optical interfaces and 4 GE combo interfaces LAN interfaces: none |
|
Extended slots |
4 SIC slots, 2 WSIC slots, and 2 XSIC slots |
|
Power module type |
Pluggable power module |
|
Weight |
8.85 kg (19.51 lb) |
|
Dimensions (W x D x H) |
442.0 mm x 470.0 mm x 88.1 mm |
Table 2 shows the recommended elements for the Huawei Router - AR2240C.
|
Model |
Description |
|
AC power module |
|
|
AR0MPSAP3500 |
350W AC Power Module |
|
DC power module |
|
|
AR0MPSDP3500 |
350W DC Power Module |
|
WAN interface card |
|
|
AR-1E3T3M-W |
1-Port Channelized/Unchannelized E3/T3 WAN Interface Card |
|
AR0MSDE11A00 |
1-Port Fractional Channelized E1/T1 WAN Interface Card |
|
xDSL interface card |
|
|
AR01SLV1XA |
1-Port VDSL2 over POTS WAN Interface Module |
|
AR0MSLA1XA01 |
1-Port ADSL2+ ANNEX A/M WAN Interface Module |
Table 3 shows the comparison between AR2240C and AR2220E.
|
Model |
AR2240C |
AR2220E |
|
WAN Speed with Services |
1 Gbit/s
|
800 Mbit/s
|
|
Fixed WAN Ports |
2 x GE Combo |
2 x GE |
|
Fixed LAN Ports |
4 x GE + 4 x GE SFP +2 x GE Combo |
3 x GE (1 x Combo) |
|
Wireless Controller |
Wireless Controller is integrated in software |
|
|
Memory |
2 GB |
1 GB |
AR2204C Specification |
|
|
WAN Speed with Services |
1 Gbit/s |
|
Firewall Performance (large packets) |
6 Gbit/s |
|
Number of recommended users |
500 |
|
Fixed WAN Ports |
4 x GE + 4 x GE SFP + 2 x GE Combo |
|
SIC Slots |
4 |
|
WSIC Slots (default/max**) |
2/4 |
|
XSIC Slots (default/max**) |
2/4 |
|
EXSIC Slot (shared with XSIC slots) |
1 |
|
DSP Slots |
0 |
|
USB 2.0 Ports |
1 |
|
Mini-USB Ports |
1 |
|
Console Port |
1 |
|
Memory |
2 GB |
|
Flash |
2 GB/8 GB |
|
Maximum Power |
350W (Single Power Module) 700W (Dual Power Module) |
|
Redundant Power Supply |
Internal: AC, DC |
|
AC Power |
100V to 240V |
|
Frequency |
50 Hz/60 Hz |
|
DC Power |
- |
|
Dimensions (height x width x depth) |
88.1 mm x 442 mm x 470 mm |
|
Weight |
4.95 kg (without power module and interface card) |
|
Ambient Temperature |
0°C to 45°C |
|
Relative Humidity |
5% to 95% (non-condensing) |
