Huawei eSFP-FE-LX-SM1310 is Optical Transceiver. It’s a Single-mode Module.
Table 1 shows the Quick Specs.
|
Product Code |
eSFP-FE-LX-SM1310 |
|
Transceiver form factor |
eSFP |
|
Transmission speed |
100 Mbit/s |
|
Center wavelength (nm) |
1310 |
|
Standard compliance |
100base-LX |
|
Connector type |
LC |
|
Applicable cable and maximum transmission distance |
Single-mode fiber: 15 km |
|
Transmit power (dBm) |
-15.0 to -8.0 |
|
Maximum receiver sensitivity (dBm) |
-31.0 |
|
Overload power (dBm) |
-8.0 |
|
Extinction ratio (dB) |
8.2 |
|
Operating temperature |
0°C to 70°C (32°F to 158°F) |
|
Net Dimension(D x W x H mm) |
110 x 75 x 40 |
Table 2 shows the Huawei hot switches which support eSFP-FE-LX-SM1310.
|
Model |
Description |
|
S2700-26TP-EI-DC |
24 x Ethernet 10/100 ports, 2 dual-purpose 10/100/1000 or SFP, DC -48V |
|
S2700-52P-EI-AC |
48 x Ethernet 10/100 ports, 4 Gig SFP, AC 110/220V |
|
S2700-26TP-EI-AC |
4 x Ethernet 10/100 ports, 2 dual-purpose 10/100/1000 or SFP, AC 110/220V |
|
S2700-9TP-PWR-EI |
8 x Ethernet 10/100 ports, PoE+, 1 dual-purpose 10/100/1000 or SFP, AC 110/220V |
|
S2700-26TP-PWR-EI |
24 x Ethernet 10/100 ports, 2 dual-purpose 10/100/1000 or SFP, PoE+, without power module |
|
S2700-9TP-EI-AC |
8 x Ethernet 10/100 ports, 1 dual-purpose 10/100/1000 or SFP, AC 110/220V |
|
S3700-28TP-EI-AC |
24 x Ethernet 10/100 ports, 2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP, AC 110/220V |
|
S3700-28TP-SI-AC |
24 x Ethernet 10/100 ports, 2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP, AC 110/220V |
|
S3700-28TP-PWR-SI |
24 x Ethernet 10/100 PoE+ ports,2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP,with 500W AC power supply |
Table 3 shows the comparison of SFP-FE-SX-MM1310 and eSFP-FE-LX-SM1310.
|
Item |
SFP-FE-SX-MM1310 |
eSFP-FE-LX-SM1310 |
|
Transceiver form factor |
SFP |
eSFP |
|
Transmission speed |
Fast Ethernet |
100 Mbit/s |
|
Center wavelength (nm) |
1310 |
1310 |
|
Standard compliance |
100base-FX |
100base-LX |
|
Connector type |
LC |
LC |
|
Applicable cable and maximum transmission distance |
Multimode fiber (50 μm or 62.5 μm diameter): 2 km |
Single-mode fiber: 15 km |
|
Transmit power (dBm) |
-19.0 to -14.0 |
-15.0 to -8.0 |
|
Maximum receiver sensitivity (dBm) |
-30.0 |
-31.0 |
|
Overload power (dBm) |
-14.0 |
-8.0 |
|
Extinction ratio (dB) |
10 |
8.2 |
|
Operating temperature |
0°C to 70°C (32°F to 158°F) |
0°C to 70°C (32°F to 158°F) |
|
Net Dimension(D x W x H mm) |
145 x 80 x 35 |
110 x 75 x 40 |
eSFP-FE-LX-SM1310 Specification |
|
|
Transceiver form factor |
eSFP |
|
Transmission speed |
100 Mbit/s |
|
Center wavelength (nm) |
1310 |
|
Standard compliance |
100base-LX |
|
Connector type |
LC |
|
Applicable cable and maximum transmission distance |
Single-mode fiber: 15 km |
|
Transmit power (dBm) |
-15.0 to -8.0 |
|
Maximum receiver sensitivity (dBm) |
-31.0 |
|
Overload power (dBm) |
-8.0 |
|
Extinction ratio (dB) |
8.2 |
|
Operating temperature |
0°C to 70°C (32°F to 158°F) |
|
Net Dimension(D x W x H mm) |
110 x 75 x 40 |
