Table 1 shows the Quick Specs.
|
Product Code |
AC6005-8-8AP |
|
Ports |
6 x GE + 2 x GE Combo |
|
Power Supply |
AC |
|
Forwarding Capability |
4 Gbit/s |
|
Maximum Number of Managed APs |
256 |
|
Maximum Number of Access Users |
2K |
|
AP-AC Networking |
Layer 2 or Layer 3 networking |
|
Forwarding Modes |
Direct forwarding (distributed forwarding or local forwarding) or tunnel forwarding (centralized forwarding) |
|
AC Active/Standby Mode |
1+1 HSB or N+1 backup |
|
Dimensions (W x D x H) |
320 mm x 233.6 mm x 43.6 mm |
|
Net Weight |
2.05 kg |
Note：
|
① |
MODE button |
④ |
Console Port |
|
② |
6 × 10/100/1000BASE-T Ethernet electrical ports. |
⑤ |
USB Port |
|
③ |
Two Pairs of combo ports |
⑥ |
LEDs Area |
Table 2 shows the LEDs Area description.
|
Indicator/Button |
Status |
Description |
|
Power Supply Indicator: PWR |
Off |
Power supply not on |
|
Steady green |
Power supply working properly |
|
|
System Status Indicator: SYS |
Off |
System not operating |
|
Steady green |
Fast blinking: System starting Slow blinking: System running properly |
|
|
Steady red |
System cannot start normally or there is an overheat or fan alarm |
|
|
State Mode Indicator: STAT |
Off |
State mode not selected |
|
Steady green |
Service port indicator works in default mode (STAT). In this mode, the indicator shows the port status |
|
|
Speed Mode Indicator: SPED |
Off |
Speed mode not selected |
|
Steady green |
Service port indicator shows port speed. After 45 seconds, service port indicator automatically returns to default mode (STAT) |
Table 3 shows the recommended Optical Transceivers for AC6005-8-8AP.
|
Model |
Description |
|
Electrical Transceiver, SFP, GE, Electrical Interface Module (100m, RJ45) |
|
|
eSFP-GE-SX-MM850 |
Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.55km, LC) |
|
SFP-GE-LX-SM1310 |
Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
|
S-SFP-GE-LH40-SM1310 |
Optical Transceiver, eSFP, GE,S ingle-mode Module (1310nm, 40km, LC) |
|
S-SFP-GE-LH40-SM1550 |
Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 40km, LC) |
Table 4 shows the comparison of AC6005-8-8AP and AC6005-8-PWR-8AP.
|
Models |
AC6005-8-8AP |
AC6005-8-PWR-8AP |
|
PoE Available |
No |
Yes, it supports PoE power supply on six ports. |
|
Ports |
6 x GE + 2 x GE Combo |
6 x GE + 2 x GE Combo |
|
Power Supply |
AC |
AC |
|
Forwarding Capability |
4 Gbit/s |
4 Gbit/s |
AC6005-8-8AP Specification |
|
|
Technical specifications |
*Dimensions (H x W x D):43.6 mm x 320 mm x 233.6 mm *Weight: 2.9 kg *Operating temperature: –5oC to 50oC *Storage temperature: –40oC to +70oC *Humidity: 5% to 95% *Input voltage: 100 V AC to 240 V AC; 50/60 Hz *Maximum voltage range: 90 V AC to 264 V AC, 47 Hz to 63 Hz *Maximum power consumption: 163.6 W (device power consumption: 39.6 W, PoE: 124 W) |
|
Interface type |
*8 x GE interfaces, among which the last two are multiplexed with two optical interfaces as combo interfaces *One RJ45 serial maintenance interface *One Mini USB serial maintenance interface |
|
LED indicator |
*Power module indicator (PWR): indicates the power-on status of the device. *System running status indicator (SYS): indicates the running status of the device. *Service network port indicator: indicates the data transmission status, interface rate, and PoEstatus of a network port. |
|
Number of managed APs |
256 |
|
Number of SSIDs |
16K |
|
Number of APs controlled by each license |
1, 8, 32 |
|
Number of access users |
Entire device: 2K |
|
User group management |
The AC supports 128 user groups: *Each user group can reference a maximum of 8 A CLs. *Each user group can associate with a maximum of 128 A CL rules. |
|
Number of MAC addresses |
4K |
|
Number of VLANs |
4K |
|
Number of ARP entries |
4K |
|
Number of routing entries |
8K |
|
Number of multicast forwarding entries |
2K |
|
Number of DHCP IP address pools |
64 IP address pools, each containing a maximum of 8K IP addresses |
