Huawei AP1050DN-S is a wireless access point (AP) targeted at the SMB distribution market. It provides comprehensive service support capabilities and features high reliability, high security, simple network deployment, automatic AC discovery and configuration, and real-time management and maintenance, which meets network deployment requirements. The AP complies with 802.11n and 802.11ac protocols and can provide gigabit access for wireless users.
Table 1 shows the Quick Specs.
|
Product Code |
AP1050DN-S |
|
Dimensions (H x W x D) |
35mm x 170mm x 170mm |
|
Interface type
|
1 x 10/100/1000M self-adaptive Ethernet interface (RJ45) Console interface (RJ45 x 1) |
|
LED indicator |
Indicates the power-on, startup, running, alarm, and fault status of the system. |
|
Power input |
DC: 12 V ± 10% PoE power supply: in compliance with IEEE 802.3af/at |
|
Maximum power consumption
|
8.1 W NOTE The actual maximum power consumption depends on local laws and regulations. |
|
Antenna gain
|
2.4G: 5 dBi 5G: 5 dBi |
|
Maximum number of SSIDs for each radio |
16 |
|
Maximum number of users |
≤ 256 |
Huawei AP1050DN-S provides these features:
• 802.11ac Wave 2 standards compliance, delivering services simultaneously on 2.4G and 5G radios; 200 Mbit/s at 2.4 GHz; 433Mbit/s at 5 GHz; and 633 Mbit/s for the device.
• One GE uplink port.
• Supports the Fat, Fit, and cloud modes and enables Huawei cloud-based management platform to manage and operate APs and services on the APs, reducing network O&M costs.
Table 2 shows the comparison.
|
Product Code |
AP1050DN-S |
AP2050DN-E |
|
Dimensions (H x W x D) |
35mm x 170mm x 170mm |
36mm x 86mm x 140mm |
|
Interface type
|
1 x 10/100/1000M self-adaptive Ethernet interface (RJ45) Console interface (RJ45 x 1) |
Uplink: 1 x GE Downlink: 4 x GE 2 x Pass-through RJ45 port 1 x USB port |
|
Built-in Bluetooth |
\ |
BLE4.1 |
|
Power input |
DC: 12 V ± 10% PoE power supply: in compliance with IEEE 802.3af/at |
Power adapter: 48 V ± 5% PoE power supply: in compliance with IEEE 802.3af/at |
|
PoE out |
\ |
10 W |
|
Maximum power consumption
|
8.1 W
|
11.5W (excluding the output power of the USB port and PoE_OUT port) |
|
Antenna type |
Built-in dual-band omnidirectional antennas |
Built-in dual-band omnidirectional antennas |
|
Antenna gain
|
2.4G: 5 dBi 5G: 5 dBi |
2.4G: 4 dBi 5G: 5 dBi |
|
Maximum transmit power
|
2.4G: 20 dBm (combined power) 5G: 20 dBm (combined power) |
2.4G: 21 dBm (combined power) 5G: 20 dBm (combined power) |
AP1050DN-S Specification |
|
|
Dimensions (H x W x D) |
35mm x 170mm x 170mm |
|
Weight |
0.41 kg |
|
Interface type
|
1 x 10/100/1000M self-adaptive Ethernet interface (RJ45) Console interface (RJ45 x 1) |
|
LED indicator |
Indicates the power-on, startup, running, alarm, and fault status of the system. |
|
Power input |
DC: 12 V ± 10% PoE power supply: in compliance with IEEE 802.3af/at |
|
Maximum power consumption
|
8.1 W NOTE The actual maximum power consumption depends on local laws and regulations. |
|
Operating temperature |
–10°C to +50°C |
|
Storage temperature |
–40°C to +70°C |
|
Operating humidity |
5% to 95% (non-condensing) |
|
Altitude |
–60 m to +5000 m |
|
Dustproof and waterproof grade |
IP41 |
|
Atmospheric pressure |
53 kPa to 106 kPa |
|
Antenna type |
Built-in dual-band omnidirectional antennas |
|
Antenna gain
|
2.4G: 5 dBi 5G: 5 dBi |
|
Maximum number of SSIDs for each radio |
16 |
|
Maximum number of users |
≤ 256 |
|
Maximum transmit power
|
2.4G: 20 dBm (combined power) 5G: 20 dBm (combined power) NOTE The actual transmit power depends on local laws and regulations. |
|
Power increment |
1 dBm |
|
Receiver sensitivity
|
2.4 GHz 802.11b：–97dBm @ 1 Mbit/s；–91dBm@ 11 Mbit/s 2.4 GHz 802.11g：-93dBm @ 6 Mbit/s； -78dBm @ 54 Mbit/s 2.4 GHz 802.11n (HT20)：-93 dBm @ MCS0；-72dBm @ MCS15 2.4 GHz 802.11n(HT40)：-90 dBm @ MCS0； -71 dBm @ MCS15 5 GHz 802.11a ：-93 dBm @ 6 Mbit/s； -77dBm @ 54 Mbit/s 5 GHz 802.11n (HT20)：-92 dBm @ MCS0； -72 dBm @ MCS15 5 GHz 802.11n (HT40)：-89 dBm @ MCS0； -70dBm @ MCS15 5 GHz 802.11ac (VHT20)：-92 dBm @ MCS0NSS1； -71 dBm @ MCS8NSS2 5 GHz 802.11ac (VHT40)：-90 dBm @ MCS0NSS1； -63 dBm @ MCS9NSS2 5 GHz 802.11ac (VHT80)：-86 dBm @ MCS0NSS1； -60 dBm @ MCS9NSS2 |
|
Safety standards
|
UL 60950-1 IEC 60950-1 EN 60950-1 GB 4943 CAN/CSA 22.2 No.60950-1 |
|
Radio standards
|
ETSI EN 300 328 ETSI EN 301 893 RSS-210 AS/NZS 4268 FCC Part 15C: 15.247 FCC Part 15C: 15.407 China's SRRC document [2002] No. 353 China's SRRC document [2002] No. 277 China's SRRC document [2012] No. 620 |
|
EMC standards
|
EN 301 489-1 EN 301 489-17 ETSI EN 60601-1-2 FCC Part 15 ICES-003 YD/T 1312.2-2004 ITU k.20 GB 9254 GB 17625.1 AS/NZS CISPR22 EN 55022 EN 55024 CISPR 22 CISPR 24 IEC61000-4-6 IEC61000-4-2 |
|
IEEE standards
|
IEEE 802.11a/b/g IEEE 802.11n IEEE 802.11ac IEEE 802.11h IEEE 802.11d IEEE 802.11e IEEE 802.11k IEEE 802.11u IEEE 802.11v IEEE 802.11w IEEE 802.11r |
|
Security standards
|
802.11i, Wi-Fi Protected Access 2(WPA2), WPA 802.1X Advanced Encryption Standards(AES), Temporal Key Integrity Protocol(TKIP) EAP Type(s) |
|
EMF
|
CENELEC EN 62311 CENELEC EN 50385 OET65 RSS-102 FCC Part1&2 FCC KDB series |
|
RoHS |
2002/95/EC & 2011/65/EU |
|
REACH |
Regulation 1907/2006/EC |
|
WEEE |
Directive 2002/96/EC & 2012/19/EU |
