Features
● Supplies DC power to the Cisco Small Business WAP321 Selectable-Band Wireless Access Point when PoE cannot be used
● Offers peace-of-mind coverage with a 90-day hardware warranty Specifications Table 1 lists the specifications, package contents, and minimum requirements for the Cisco Small Business 12V Power Adapter
Product Overview
The Cisco Small Business 12V Power Adapter is designed to work specifically with the Cisco WAP321 Wireless-N Selectable-Band Access Point when Power over Ethernet (PoE) cannot be used. The compact power adapter offers flexibility when PoE is not an option by supplying power to the wireless access point via a standard AC outlet.
|
Specifications |
Description | ||
|
Power output plug |
90-degree DC power plug 5.5 x 2.1 x 9.5 mm barrel |
||
|
Polarity |
|
||
|
Physical Interfaces |
|||
|
Input power |
AC input voltage: 90-264 VAC AC input current: 0.5A @ 100-240 VAC AC frequency: 50-60 Hz |
||
|
Physical Specifications |
|||
|
Physical dimensions (W x D x H) |
1.77 x 2.62 x 1.3 in. or 44 x 66.67 x 33 mm |
||
|
Weight |
0.2 lb or 89 g |
||
|
Environmental |
|||
|
Power |
AC input voltage: 90-264 VAC AC input current: 0.5A @ 100-240 VAC AC frequency: 50-60 Hz |
||
|
Certifications |
FCC Class B, CE, UL/cUL, C-Tick, RoHS |
||
|
Operating temperature |
0⁰ to 40⁰C (32⁰ to 104⁰F) |
||
|
Storage temperature |
-20⁰ to 70⁰C (-4⁰ to 158⁰F) |
||
|
Operating humidity |
10% to 85% noncondensing |
||
|
Storage humidity |
5% to 90% noncondensing |
||
|
Package Contents |
|||
|
• Cisco Small Business 12V Power Adapter • Power cord • Pointer card |
|||
|
Minimum Requirements |
|||
|
• Cisco WAP321 Wireless-N Selectable-Band Access Point with PoE |
|||
|
Warranty |
|||
|
Power Adapter |
90-day hardware warranty |
||
Ordering Information
|
Part Number SB-PWR-12V-EU |
Description Cisco Small Business 12V Power Adapter (Europe) |
