HPE Proliant DL580 Gen9 E7-4830v4 1P 32GB-R P830i/2G 331FLR-SFP 1200W RPS Server comes standard with an Intel 14-core Xeon E7-4830 v4 processor (2.0GHz, 14-core, 35MB cache, 115W), which supports Up to 4 processors; Comes standard with four Smart Socket intelligent CPU bays; Integrated iLO 4 remote management; Comes standard with 2x16GB (32GB) PC4-2400T-R DIMMs (DDR4) memory, up to 6TB fully buffered DIMMs (DDR4- 2400) memory, standard with 1 memory cartridge, maximum support for 8 memory cartridges, and can be configured for mirroring, online backup or advanced ECC mode; built-in Smart Array P830i/2GB FBWC array controller with 5 SFF hot plugs as standard Hard disk slot, up to 10 SFF hot-swappable hard drives, standard without hard disk, standard 9 PCI-E 3.0 slots, including 4 PCI-E 3.0 x8, 5 PCI-E 3.0 x16; standard 4-port Gigabit 331FLR Ethernet card; upgradeable to 2-port x10Gb Ethernet card; or 2-port x10Gb Flex Fabric NIC; standard with 2 1200W hot-swappable platinum power supplies, optionally supported for redundancy (3+1); standard Hot Swap Redundant Fan (3+1); Optional External DVD-RW, 4U Rackmount with Rails and Cable Management Rack; 3 Years 7*24, 4 Hour Response Standard installation services.
Table 1 shows the Quick Specs.
|
Product Code |
816818-AA1 |
|
Processor |
Intel 14-core Xeon E7-4830 v4 processor (2.0GHz, 14-core, 35MB cache, 115W), which supports Up to 4 processors |
|
Number of processors |
1, supporting up to 4 processors |
|
Processor core available |
14 |
|
Processor cache |
35MB L3 |
|
Processor speed |
2.0GHz |
|
Form factor (fully configured) |
4U |
|
Form factor chassis |
Rack |
|
Product dimensions (H x W x D)(with bezel) |
6.88" x 17.48" x 29" (17.5cm x 44.4cm x 73.6cm) |
Figure 1 shows the front view of HPE DL580 Gen9 Server.
|
① |
CPU Memory Drawer Handle |
|
② |
Quick removal access panel |
|
③ |
Drive bays 6-10 |
|
④ |
Systems Insight Display |
|
⑤ |
Health Status LED |
|
⑥ |
Power On/Standby button and system power LED button |
|
⑦ |
NIC status LED |
|
⑧ |
UID button |
|
⑨ |
Fans 1-4 |
|
⑩ |
Drive bays 1-5 |
|
⑪ |
Discovery services connectors |
|
⑫ |
Video connector |
|
⑬ |
USB connectors (2) |
Figure 2 shows the ports and slots on the back panel of HPE DL580 Gen9 Server.
Note:
|
① |
Serial connector |
|
② |
Video connector |
|
③ |
Power Supplies 1-4 |
|
④ |
PCI expansion slots 1-9 |
|
⑤ |
Dedicated iLO connector |
|
⑥ |
FlexibleLOM ports 1-4 |
|
⑦ |
USB connectors (4) |
Table 2 shows the recommended hard drives.
|
Product number |
Description |
|
872475-B21 |
HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
872477-B21 |
HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
870753-B21 |
HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
|
872479-B21 |
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD |
Compare to Similar Items
Table 3 shows the comparison.
|
Model |
816820-AA1 |
816818-AA1 |
|
Processor |
Intel 8-core Xeon E7-4809 v4 processor (2.1GHz, 8-core, 20MB cache, 115W) | Intel 14-core Xeon E7-4830 v4 processor (2.0GHz, 14-core, 35MB cache, 115W) |
|
Number of processors |
1 Intel 8-core Xeon E7-4809 v4 processor (2.1GHz, 8-core, 20MB cache, 115W), supporting up to 4 processors |
1 Intel 14-core Xeon E7-4830 v4 processor (2.0GHz, 14-core, 35MB cache, 115W), supporting up to 4 processors |
|
Processor core available |
8 |
14 |
|
Processor cache |
20MB L3 | 35MB L3 |
|
Processor speed |
2.1GHz | 2.0GHz |
816818-AA1 Specification |
|
|
Description |
HPE Proliant DL580 Gen9 E7-4830v4 2.0GHz 14C 115W 1P 32GB-R P830i/2G 331FLR-SFP 1200W RPS Server |
|
Processor |
1 Intel 14-core Xeon E7-4830 v4 processor (2.0GHz, 14-core, 35MB cache, 115W), which supports Up to 4 processors |
|
Memory |
Comes standard with 2x16GB (32GB) PC4-2400T-R DIMMs (DDR4) memory, up to 6TB fully buffered DIMMs (DDR4- 2400) memory, standard with 1 memory cartridge, maximum support for 8 memory cartridges |
|
Array Controller |
built-in Smart Array P830i/2GB FBWC array controller |
|
Hard Disk |
Up to 10 SFF hot-swappable hard drives, standard without hard disk |
|
PCI-E |
Standard 9 PCI-E 3.0 slots, including 4 PCI-E 3.0 x8, 5 PCI-E 3.0 x16 |
|
Power Supply |
Standard with 2 1200W hot-swappable platinum power supplies, optionally supported for redundancy (3+1) |
|
Rack Type |
4U |
|
Dimensions (H x W x D) (with bezel) |
6.88" x 17.48" x 29" (17.5cm x 44.4cm x 73.6cm) |
|
Weight (approximate) |
Maximum: (all hard drives, power supplies, DIMMs and processors installed) -- 116.56 lb (52.87 kg) Minimum: (one hard drive, two power supplies, four DIMMs, and two processors installed) -- 70.94 lb (32.18 kg) |
