Brand : HPE
Type : HPE Storages
Detail :

HPE MSA 2050 SAN NEBS Certified DC Power SFF Storage

Availability : Out stock
Installation : Yes
Price : $ 18,970.00

Quick Specs

Table 1 shows the Quick Specs.

Product Code



Q1J04A - HPE MSA Storage Controllers



Q1J04A Specification

Q1J04A Specification

Installed Devices Modules Qty 0
Supported Devices Modules Qty 24
Supported Interface Serial Attached SCSI 2
Dimensions & Weight
Width 29 in
Depth 26 in
Height 11 in
Weight 81.57 lbs
Environmental Standards
ENERGY STAR Certified Yes
Expansion Bays
Form Factor (metric) 6.4 cm SFF
Optical Storage
Type None
Bay Provided
Form Factor 2.5 SFF
Total Qty 24
Free Qty 24
Environmental Parameters
Sound Emission 55 dBA
Min Operating Temperature 41 °F
Max Operating Temperature 104 °F
Humidity Range Operating 10 - 90% (non-condensing)
Compatibility PC, Unix
Manufacturer Hewlett-Packard
Packaged Quantity 1
Product Line HPE Modular Smart Array
Model 2050 SAN Dual Controller SFF Storage
Brand HPE
Interface Provided
Qty 4
Interface (Storage) SAS
Purpose Location Management
Connector Type RJ-45
Compliant Standards CAN/CSA C22.2 No. 60950-1-03, CCC, CISPR 22 Class A, CISPR 24, CNS 13438 Class A, EN 60950-1, EN55022, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15, GS, ICES-003:2004 Class A, IEC 60950-1, KN22 Class A, KN24, NEBS, RoHS 6/6, UL 60950-1, VCCI Class A, WEEE
Features Systems Insight Manager (SIM)
Height (Rack Units) 2
Color Category Black, Gray
Power Device
Installed Qty 2
Max Supported Qty 2
Power Consumption Operational 432 Watt
Nominal Voltage DC -40 -75 V
Power Redundancy Yes
Hot-Plug Hot-plug
Type Internal power supply
Type None
Support Details Type Limited warranty
Support Details Full Contract Period 3 years
Service & Support
Type 3 years warranty
Type Hard drive array
Max Supported Capacity 76.8 TB
Rack-mountable Rack-mountable
Maximum LUNs 512
Storage Controller
Bus Type iSCSI
RAID Level RAID 1, RAID 10, RAID 5, RAID 6
Data Transfer Rate 600 MBps
Interface Type Serial Attached SCSI 2
Buffer Size 8 GB
Installed Qty 2
Storage Controller (2nd)
Type None
System Requirements
Min Operating System Apple MacOS X, HP OpenVMS, HP-UX, Microsoft Windows, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2012 R2 with Hyper-V, Red Hat Enterprise Linux, SuSe Linux, VMware ESXi 5.x, VMware ESXi 6.x
